| Engine |
eSP, PGM-FI fuel injection system, 4-stroke, single overhead camshaft, air-cooled |
| Cylinder volume (cc) |
109.51 cc |
| Cylinder width x stroke (mm) |
47.0 x 63.1 mm. |
| Compression ratio |
10.0 : 1 |
| Clutch system |
Centrifugal automatic dry clutch |
| Transmission system (gear system) |
Automatic V-MATIC |
| Ignition system |
FULL TRANSISTORIZED |
| Engine start system |
Electric hand start |
| Size Width x Length x Height (mm) |
693 x 1,869 x 1,075 mm. |
| Wheelbase (mm) |
1251 mm. |
| Distance from ground (mm) |
149 mm. |
| Seat height (mm) |
750 mm |
| Caster Angle / Trail Distance (°’/) (mm) |
26° 22′ / 84 mm. |
| Fuel capacity (liters) |
4.2 liters |
| Frame |
Underbone eSAF press frame |
| Suspension (front) |
Telescopic |
| Suspension (rear) |
Swing unit |
| Net weight (kg) |
94 kg. |
| Brake system (front) |
Hydraulic disc brake (combined brake) |
| Brake system (rear) |
Drum brake |
| wheel |
alloy wheels |
| Tire size (front) |
100/90-12 59J tubeless type |
| Tire size (rear) |
110/90-12 64J tubeless type |
| Fuel |
Unleaded gasoline with an octane rating of 91 or higher, or containing a maximum of 20% ethanol alcohol. |
